Industrial Fanless mini P

Name: Industrial Fanless mini PC VenBOX M4B with Intel Celeron J6426/N100 2xHDMI DP LAN 8xUSB
Brand: Eglobal
SKU: M4B-J6426
Price: 15968.05 UAH
Availability: InStock

SKU

M4B-J6426

Пропустить и перейти к галереям изображений

Перейти к началу галереи изображений

15 968,05 ₴

В наличии

Fanless mini PC in a silent small metal case with Intel Celeron J6412 CPU, 2*COM (RS-232), 2*LAN (RJ-45), 3*independent video outputs: 2*HDMI and 1*DP for Industrial grade applications like Pfsense or VPN Firewall.

CPU: Onboard Intel Celeron J6412/N100
OS: Windows 8/10/11/Linux/IoT10/11
Memory: 1 x SO-DIMM DDR4 slot, support 4GB/8GB/16GB
Storage:
- 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s;
- 1 x M.2 slot for NVME 2280 SSD;
- 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s
Video: Intel® UHD Graphics
WiFi: 1 x M.2 2230 slot for Wi-Fi & Bluetooth module
Display: 2 x HDMI 1.4, 1 x DP 1.2
Functions: Watchdog, Auto power on, Wake-On-LAN, PXE

Notify me when the price drops

Industrial Fanless mini PC VenBOX M4B with Intel Celeron J6426/N100 2xHDMI DP LAN 8xUSB is available to buy in increments of 1

Категории: Сфера услуг, Промышленность, Windows mini PC, Промышленные ПК

Бесплатная доставка

При заказе от 100 €

Возврат в течении 14 дней

По любой причине

Безопасная оплата

100% безопасные платежи

Поддержка 24/7

Выделенная поддержка

Details

Product Highlights

Pre-installed OS & Processor
- Fanless Mini PC M4B uses Celeron J6412 or N100 Quad-core; CPU and GPU performance is good enough to handle easy tasks.
- Supports Windows 8/10/11, Linux, Ubuntu and others open-source systems.
- Support Auto Power On and PXE boot etc.
Expandable RAM & Storage Capacity
- Fanless Mini PC M4B comes with 4/8/16 GB DDR4L RAM and 32G/128/256/512/1024/2048GB mSATA SSD. The memory is only 1x SODIMM slot, max support 16GB. The storage is 1x mSATA and can be upgraded even to 4TB. Large storage can meet the hardware requirements of different network security firewall software and other applications.
Gigabit Ethernet port
- Fanless Mini PC M4B supports Gigabit Ethernet to keep stable and high speed. It has good compatibility with soft routing, firewalls and other network applications.
- This compact PC has more I/O interfaces to meet your needs: 2*HDMI, 1*DP, RJ45 LAN, 6*USB 2.0, 2*USB 3.0, 2*Audio, 1*DC IN
Portable & Silent
- Fanless Mini PC M4B built for home, office use and also for industrial solutions. It’s only 135*127*38.7mm and 0.8 kg to save space. In addition, M4B uses a fanless cooling design and only has a 10W TDP to maintain low power consumption to save energy and 7x24 hours of quiet running.

Specifications

Basic Information:
CPU	Onboard Intel Celeron J6412 / N100
TDP	10W
Motherboard	120 x 120mm customized size
BIOS	American Megatrends Inc
Chipset	Elkhart Lake
Memory	1* SO-DIMM DDR4 Slot,Support 4GB/8GB/16GB DDR4-2133, LPDDR3-1866, DDR3L-1600
OS	Windows 8/10/11/Linux/WES10
PXE	YES
Audio	Intel High Definition Audio Controller
Network	1 x Realtek 811H Gigabit Ethernet Controller10/100Mbps/1000Mbps BaseT LAN
Video	Intel® UHD Graphics
Input/output port:
Switch	1 x Power On/Off Switch
Power	1 x 12V DC In
USB	6x USB2.0, 2 x USB3.0
Display	2 x HDMI 1.4, 1 x DP 1.2
LAN	1x RJ45 Giga LAN
Audio	1 x MIC, 1 x SPK
Storage:
MSATA	1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s
M.2	1 x M.2 slot for NVME 2280 SSD
SATA	1 x SATA3.0 slot for SATA HDD or SSD, , support 6Gb/s
Wi-Fi:
Module	1 x M.2 2230 slot for Wi-Fi & Bluetooth module
Antenna	2 x inner RF cables and 2 x external antennas
Power and Working Environment
Input	100-240V AC/50-60Hz
Output	12V~+19V, recommend 12V/5A
Operating Temperature	-20°C/+60°C
Storage Temperature	-30°C/+70°C
Relative Humidity	10%~90% @30°C (non-condensing)
Product Dimension & Details
Size	13512738.7mm
Weight	Net 0.8kg, Gross 1kg
Shell	Black color aluminum alloy (any customized color for bulk order)
Cooling Mode	Fanless
Functions	Watchdog, Auto power on, Wake-On-LAN, PXE
Package Content
Standard	1xMini PC, 1xPower Adapter, 1xPower Cord, Wi-Fi antennas, 1xHDMI cable, 1xScrews Bag, 1xUser Manual (ebook)
Optional	1xUser Manual (printed), 1xVESA mount

What's in the package:

1x Mini PC
1x Power Adapter
1x EU Power cable
1x SATA power & data cable
1* HDMI cable
2* Wi-Fi antennas
1* VESA Mount (Optional)

Fanless Mini Computer © Onboard Intel Celeron J6412 © Slim dimension 135*127*38.7mm © Support 2 x HDMI 1.4+DP 1.2 triple displays

Intel Celeron J6412 N100 RJ45 Giga LAN 135*127*38.7mm 2xHD 1.4 6 x USB2.0, 2 x USB3.0 DP 1.2 TDP 10W Full Aluminum Alloy shell M.2 2230 slot for Wi-Fi & Bluetooth module

CPU Onboard Intel Celeron J6412 OS Windows 10/Linux/WES10 1 x SO-DIMM DDR4 Slot, Support 4GB/8GB 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s Storage 1 x M.2 slot for NVME 2280 SSD 1 x SATA3.0 slot for SATA HDD or SSD,, support 6Gb/s Video | Intel® UHD Graphics WiFi I 1 x M.2 2230 slot for Wi-Fi & Bluetooth module Display Functions 2 x HD 1.4, 1 x DP 1.2 Watchdog, Auto power on, Wake-On-LAN, PXE 10W Water EGLOBAL Mini PC Desktop PC

INSTALLATION Fix VenBOX Mini PC back of the monitor using VESA Mount

RICH INTERFACES TO MEET MORE NEEDS SUPPORT 2 X HD 1.4+DP 1.2 THREE-SCREEN 4K OUTPUT AT THE

SHOW DETAILS Aluminum Alloy Rugged and durable, aluminum alloy, thermally conductive shell, fast heat dissipation, strong pressure resistance, dust and corrosion resistance. 8 x USB Interface 6 x USB2.0, 2 x USB3.0 More equipments can be connected. 2xHD 1.4, 1 xDP 1.2 Support 2 x HDMI 1,4+DP 1.2 Three displays output synchronously. RJ45 Giga LAN 1 x RJ45 Gigabit Ethernet LAN, Communication is faster and more stable.

RICH INTERFACES O Power On/Off Switch 0 2 x USB3.0 0 6 x USB2.0 O SPK © RJ45 Giga LAN © 2xHD 1.4 © MIC © DP 1.2 © 12V DC In

APPLICATION Industrial Site Entertainment Venue Digital Signage Smart Robot Self-service Inquiry Machine Commercial Organization

Details about the Operating System

Trial Operating System:

Default installed our trial not activated OEM Windows 10 IoT for free, other languages can be selected among Russian, Spanish, Portuguese, French, German, Arabic, Italian, Japanese, Turkish, Greek etc.
Please inform us which language you want to install. Other systems we can install free OS like Linux, Ubuntu, OpenElec etc. if you need them.
The seller is irresponsible and makes no compensation for the function of the trial OEM system. You also can install OS and software package by yourself. F11 key boot from USB Drive. ESC key enters into BIOS.
